Anomaly Link Detection Unmanaged Power Over Ethernet POE Switch 2-4 Port 10/100/1000M For Ip Cameras

Product Categories

Shenzhen Optfocus Technology Co., Ltd.

Contact Now

Name: Anomaly Link Detection Unmanaged Power Over Ethernet POE Switch 24 Port 101001000M For Ip Cameras
Brand: OPTFOCUS
Price: 1 USD

Brand Name : OPTFOCUS

Model Number : OFS-GSF1T2

Place of Origin : Shenzhen China

MOQ : 1

Payment Terms : T/T

Supply Ability : 5000 pieces per one week

Delivery Time : 5-7 working days

Packaging Details : 215mm×138 mm× 56mm

Product Name : 2-port 10/100/1000Mbps + 1-port 1000Mbps SFP Fiber

Product Model : OFS-GSF1T2

Power Supply external PS : Input Voltage: DC52V (48～55V)

PoE Specification : Output Voltage: DC48V

LED Indicators : Power: PWR; Link;POE ; Link/Act

Product Weight : 0.5 KG

Product size : 93mm× 70mm× 26mm

Contact Now

Anomaly link detection unmanaged Power Over Ethernet POE Switch 2-4 port 10 / 100/ 1000M for ip cameras

Technical items	Description
Product Name	2-port 10/100/1000Mbps + 1-port 1000Mbps SFP Fiber
Product Model	OFS-GSF1T2
Network Protocols	IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;IEEE802.3u;100Base-TX;IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x;
Network Media	10BASE-T: Cat3,4,5 UTP(≤100 meter)
	100BASE-TX: Cat5 or later UTP(≤100 meter)
	1000BASE-TX: Cat6 or later UTP(≤100 meter)
Fiber Media	Multi-mode: 2KM
Fiber Media	Single-mode: 20/40/60/80KM
Performance Specification	Bandwidth: 6Gbps
	Packet Buffer Memory:2M
	Packet Forwarding Rate:1488000pps/port
	MAC Address Table:1K /port
PoE Specification	PoE Standard: IEEE802.3af/ IEEE802.3at
	PoE ports: 2 port support PoE
	Power Output:
	Max. 15.4 watts (IEEE 802.3af)
	Max. 30 watts (IEEE 802.3at)
	PoE port Auto detect AF/AT devices
	Output Voltage: DC48V
	Power Pin Assignment:1/2+;3/6-
	Power Type: End-span( Mid-span optional)
Forwarding Mode	Store-and-Forward
LED Indicators	Power: PWR; Link;POE ; Link/Act
Power Supply	Input Voltage: DC52V (48～55V)
Working Environment	Working temperature: -10～55℃ ; Storage temperature: -20～75℃
Working Environment	Relative Humidity: 5%~95 %( no condensation)
Installation	DIN-Rail or Wall mounts,Optional,Default device is not
Packing List	1× Media Converter
	1×User Manual/Certificate of quality/Warranty card
	1×power adapter
MTBF	100,000 hours
Weight & Size	Product Weight: 0.5 KG
	Packing weight: 1.1 KG
	Product size (L×W×H): 93mm× 70mm× 26mm
	Packing size(L×W×H): 215mm×138 mm× 56mm
Warranty	1-years

Most popular & high quality 2* 10/100/1000Base-T RJ45,1* 1000M fiber SFP ports, without SFP module,POE, external PS
